Micro Low Flow meter : SKU: FMTE4

SKU: FMTE4 Micro Flowmeter :: Low flow meter 1 - 250 cc/min (0.015-4 gph) Stainless Stee/PTFE, Pulse Output

DEA Micro Flowmeter :: Low flow meter  / minute (OEM Model)



FMTE4 Micro Flowmeter :: Low flow meter
OEM Version: 5 Pcs per order minimum
1 - 250 cc/min (0.015-4 gph)
Stainless Stee/PTFE O-rings,
Individually Calibrated

Specifications:

Nominal Sizes
DN6 :: 1/4" NPT Female threaded connection

Measuring Range
0.001 - 0.25 Litres/Minute (0.015 - 4 USG/Hour)
Accuracy
Better than +/- 1%
Repeatability
+/- 0.1%
Operating Pressure
Max 35 bar :: 500 psi
Ambient Temperature
-20 °C to +60 °C (-20 °F - 140 °F)
Medium Temperature
-40 °C to +80 °C (-40 °F - 180 °F)
Construction
316 Stainless Construction / PTFE O-RIngs
Signal
5V TTL Pulse Output (8-20V DC Required) NPN/PNP/4-20mA/Comms options
Displacement
Approx 50 pulses per cc
Viscosity
Max 25 Centipoise (100 SSU) Higher viscosity reduces the meters low flow range
