Non rise bellows globe valve
Straight Type,Stem with bellow seal,bellow seal Secondary sealing,gland packing,Lubricating nipple,Position indicator ,None-rising handwheel,Non-rotation lock of stem,Protective cover of stem.Silfoniniai gaubtiniai ventiliai.Zawory mieszkowe
Material
GP240GH (1.0619/GS-C25),G-X6CrNi18.9(1.4308),G-X6CrNiMo18.10 (1.4408)
ASTM A216 WCB WCC;ASTM A217 WC1 WC6 WC9;ASTM A351 CF8,A351 CF8M,
A351 CF3,A351 CF3M,A351 CN7M;.ASTM A352 LC1 LCB LCC LC3 or by customers
(Cast Steel, Alloy Steel, Stainless Steel, Special Steel)
Standard
Nominal diameter(DN): DN10-DN500
Nominal pressure(PN): PN16,PN25,PN40,PN63,PN100
Design&manufacture standard :EN 13709/DIN 3356
Face to face standard:EN 558-1/DIN 3202
Flange ends standard:EN 1092-1/DIN 2501
Testing:EN 12266/DIN 3230
